Drafting & Shop Drawing Services
Accurate, CSA/AAMA-aligned drawings and submittals—coordinated with your architect.
Coordination, Accuracy, Approval.
We prepare window and door shop drawings, architectural details, and full submittal packages that align with CSA/AAMA guidelines. Expect clear dimensions, anchorage and interface details, and fast revisions—coordinated with your architect so approvals move quickly and installation stays on schedule.
Fabrication-Ready Shop Drawings.
We translate architectural intent into precise, buildable shop drawings—elevations, sections, details, and hardware schedules—organized for fast approvals and clean fabrication.
Field-Verified & Coordinated.
Site measurements and clash coordination are baked in. We verify critical dimensions, align with structural/MEP, and issue revision-controlled sets so installers arrive with accurate, confidence-ready plans.
TQC provides window and door shop drawings, architectural detailing, and submittal documentation for manufacturers, builders, and contractors.
Our drafting team transforms architectural concepts into precise, build-ready documentation that ensures clarity, accuracy, and full compliance with CSA and AAMA standards. Every drawing is coordinated with the project’s architect and design team to avoid conflicts, speed approvals, and maintain schedule integrity.
We prepare:
Detailed plans, elevations, and sections
Frame and anchoring details
Head, jamb, and sill conditions
Glazing, hardware, and material callouts
Complete submittal packages in PDF format
Our process emphasizes accuracy and coordination at every step—helping you reduce RFIs, streamline approvals, and achieve clean, consistent installations.
